A-Frame House Plans Page 1
| 264850 |
Price Code: [A]
|
Total Finished Area: 582 sq. ft. |
 Click on thumbnail for larger image... |
|
Compact Floor Plan This economical, compact floor plan is perfectly suited for a narrow lot or would minimize the environmental impact of any piece of property. Even though reduced to bare essentials the living area boasts a two storey high vaulted ceiling. The living area window wall maximizes all the available views and floods the room with natural light. The sleeping loft shares these same sight lines. Plans come with a crawl space foundation plan. Ceiling Heights: 1st Floor 8' to 19', 2nd Floor 3' to 10'. Click here for plans. |
|||
|
Main Floor Area: 384
Second Floor Area: 198 Third Floor Area:
Basement Area: Loft/Bonus Rm Area:
Width: 24'0 Depth: 36'0 Max. Ridge Height: 23'0 Roof Pitch - Primary: 12.00/12 Secondary: /12 Exterior Wall: 2x6 Ceiling Height - Main: 8'0 Second: 10'0 Loft/Bonus Rm: Basement: Bedrooms: 1 Baths: Half-baths: |
|||
| 131054 |
Price Code: [A]
|
Total Finished Area: 761 sq. ft. |
 Click on thumbnail for larger image... |
|
Additional ceiling height information: Great Room and Dining Area - 18'2". Click here for plans. |
|||
|
Main Floor Area: 604
Second Floor Area: 157 Third Floor Area:
Basement Area: Loft/Bonus Rm Area:
Width: 22'0 Depth: 28'11 Max. Ridge Height: 21'2 Roof Pitch - Primary: 12.00/12 Secondary: /12 Exterior Wall: 2x6 Ceiling Height - Main: 8'0 Second: 9'4 Loft/Bonus Rm: Basement: Bedrooms: 2 Baths: 1 Half-baths: |
|||
| 220972 |
Price Code: [A]
|
Total Finished Area: 796 sq. ft. |
 Click on thumbnail for larger image... |
|
Multi-featured Vacation Cottage
This multi-featured vacation cottage has all the necessary amenities to provide its owner with many hours of enjoyable relaxation. It's compact size will make it very economical to construct and its simple design easy to construct for even the novice builder. Finished in cedar and shakes it will blend into any wooded setting very nicely. Click here for plans. |
|||
|
Main Floor Area: 616
Second Floor Area: Third Floor Area:
Basement Area: Loft/Bonus Rm Area: 180
Width: 22'0 Depth: 28'0 Max. Ridge Height: 22'6 Roof Pitch - Primary: 12.00/12 Secondary: /12 Exterior Wall: 2x6 Ceiling Height - Main: 8'0 Second: Loft/Bonus Rm: 7'6 Basement: Bedrooms: 2 Baths: 1 Half-baths: |
|||
| 135054 |
Price Code: [A]
|
Total Finished Area: 808 sq. ft. |
 Click on thumbnail for larger image... |
|
Soaring Design This is a great little getaway home with all the conveniences. The main Bedroom is on the first floor while up in the loft there is a bonus sleeping area. The soaring ceiling inside over the Great Room and Dining area enhances the overall spacious feeling of this design and the glass feature lets the light and view in. Click here for plans. |
|||
|
Main Floor Area: 668
Second Floor Area: Third Floor Area:
Basement Area: Loft/Bonus Rm Area: 140
Width: 22'0 Depth: 24'0 Max. Ridge Height: 21'0 Roof Pitch - Primary: 12.00/12 Secondary: /12 Exterior Wall: 2x6 Ceiling Height - Main: 8'0 Second: Loft/Bonus Rm: 9'6 Basement: Bedrooms: 2 Baths: 1 Half-baths: |
|||
| 130429 |
Price Code: [A]
|
Total Finished Area: 903 sq. ft. |
 Click on thumbnail for larger image... |
|
Perfect Vacation Home Perfect vacation home for at the ski hill or at the beach. Suitable design for a small lot. Soaring ceilings add volume to the main living areas. Window wall lets the outdoors in. Efficient u-shaped kitchen. Upper hallway views the open spaces below. Sundeck increases the overall depth. Additional ceiling height information: Living and Dining Room - 20'6". Click here for plans. |
|||
|
Main Floor Area: 676
Second Floor Area: 227 Third Floor Area:
Basement Area: Loft/Bonus Rm Area:
Width: 26'0" Depth: 26'0" Max. Ridge Height: 22'8" Roof Pitch - Primary: 12.00/12 Secondary: /12 Exterior Wall: 2x6 Ceiling Height - Main: 8'0" Second: 11'3" Loft/Bonus Rm: Basement: Bedrooms: 2 Baths: 1 Half-baths: |
|||
| 164460 |
Price Code: [A]
|
Total Finished Area: 988 sq. ft. |
 Click on thumbnail for larger image... |
|
Click here for plans. |
|||
|
Main Floor Area: 988
Second Floor Area: Third Floor Area:
Basement Area: Loft/Bonus Rm Area:
Width: 26'0" Depth: 38'0" Max. Ridge Height: 23'11" Roof Pitch - Primary: 12.00/12 Secondary: /12 Exterior Wall: 2x6 Ceiling Height - Main: 8'0" Second: Loft/Bonus Rm: Basement: Bedrooms: 2 Baths: 1 Half-baths: |
|||
| 202011 |
Price Code: [A]
|
Total Finished Area: 1011 sq. ft. |
 Click on thumbnail for larger image... |
|
Nothing Was Missed Nothing was missed when this charming little A-frame was designed. At the rear entrance...there are a stacked washer and dryer, a large closet for coats and skis and even a bench to make putting on winter footwear easier. A very roomy family area at the front features an island kitchen and a spectacular vaulted ceiling. Access to a spacious deck is made easy via french doors in the dining room. The open staircase leads you up to the sleeping loft which can be either closed off as shown or open to the living area below. Click here for plans. |
|||
|
Main Floor Area: 768
Second Floor Area: Third Floor Area:
Basement Area: Loft/Bonus Rm Area: 243
Width: 24 Depth: 38 Max. Ridge Height: 26 Roof Pitch - Primary: 13.00/12 Secondary: /12 Exterior Wall: 2x6 Ceiling Height - Main: 8 Second: Loft/Bonus Rm: 8 Basement: Bedrooms: 3 Baths: 1 Half-baths: |
|||
| 171420 |
Price Code: [A]
|
Total Finished Area: 1063 sq. ft. |
 Click on thumbnail for larger image... |
|
Click here for plans. |
|||
|
Main Floor Area: 1063
Second Floor Area: Third Floor Area:
Basement Area: Loft/Bonus Rm Area: 180
Width: 24'0 Depth: 24'0 Max. Ridge Height: 24'0 Roof Pitch - Primary: 12.00/12 Secondary: /12 Exterior Wall: 2x6 Ceiling Height - Main: 8'0 Second: Loft/Bonus Rm: 8'0 Basement: Bedrooms: 2 Baths: 1 Half-baths: |
|||
| 137144 |
Price Code: [A]
|
Total Finished Area: 1122 sq. ft. |
 Click on thumbnail for larger image... |
|
Windows Galore Windows galore and soaring ceilings create drama. Wrap-around kitchen with eating bar, views the dining area and outdoors beyond. Spacious great room is complete with a warming fireplace. Roomy sleeping loft views the living spaces below. Large sundeck enhances outdoor living. Sundeck increases overall width & depth. Click here for plans. |
|||
|
Main Floor Area: 855
Second Floor Area: Third Floor Area:
Basement Area: Loft/Bonus Rm Area: 267
Width: 24'0" Depth: 37'3" Max. Ridge Height: 22'6" Roof Pitch - Primary: 12.00/12 Secondary: /12 Exterior Wall: 2x6 Ceiling Height - Main: 8'0" Second: Loft/Bonus Rm: 10'0" Basement: Bedrooms: 3 Baths: 1 Half-baths: |
|||
| 108421 |
Price Code: [A]
|
Total Finished Area: 1172 sq. ft. |
 Click on thumbnail for larger image... |
|
Twin Dormers This cabin-style home fits everything you need into an attractive little package. The gabled entry opens into a vaulted living area and allows easy access to the kitchen, bedroom and utility areas. Rear access through a mudroom is also provided. Upstairs, twin dormers open up the loft to create a cozy master suite along with attached three-piece bath and balcony. Click here for plans. |
|||
|
Main Floor Area: 816
Second Floor Area: 356 Third Floor Area:
Basement Area: Loft/Bonus Rm Area:
Width: 30'0 Depth: 46'0 Max. Ridge Height: 23'9 Roof Pitch - Primary: 12.00/12 Secondary: /12 Exterior Wall: 2x6 Ceiling Height - Main: 8'0 Second: 8'0 Loft/Bonus Rm: Basement: Bedrooms: 2 Baths: 2 Half-baths: |
|||
