Duplex and Multi-FamilyHouse Plans Page 1
| 226191 |
Price Code: [E]
|
Total Finished Area: 884 sq. ft. |
 Click on thumbnail for larger image... |
|
A Tiny Treasure A tiny treasure best describes this narrow two-storey design, it has all of the important features carefully crafted into its plan. Considering its 16' width it has decent sized rooms with lots of closet space, a dual use bathroom, a nice utility room, and a finely proportioned living area. Both main entrances are well-sheltered and access is provided through additional doors at the front and rear. Click here for plans. |
|||
|
Main Floor Area: 884
Second Floor Area: Third Floor Area:
Basement Area: Loft/Bonus Rm Area:
Width: 16 Depth: 58'6 Max. Ridge Height: Roof Pitch - Primary: 4.00/12 Secondary: /12 Exterior Wall: 2x6 Ceiling Height - Main: 8 Second: Loft/Bonus Rm: Basement: Bedrooms: 2 Baths: 1 Half-baths: |
|||
| 195169 |
Price Code: [D]
|
Total Finished Area: 900 sq. ft. |
 Click on thumbnail for larger image... |
|
Micro Duplex This micro duplex design fits all the features of a full sized home into a very small package. Three bedrooms, an en suite and walk-in closet in the master bedroom, and a powder room on the main floor for guests, it is an excellent choice for a starter home or a compact lot situation. Floor Areas; Main Floor: 800 sq. ft. (400 per unit) Second Floor: 1000 sq.ft. (500 per unit) Click here for plans. |
|||
|
Main Floor Area: 400
Second Floor Area: 500 Third Floor Area:
Basement Area: Loft/Bonus Rm Area:
Width: 21'0" Depth: 52'0" Max. Ridge Height: 25'0" Roof Pitch - Primary: 6.00/12 Secondary: /12 Exterior Wall: 2x6 Ceiling Height - Main: 9'0" Second: 8'0" Loft/Bonus Rm: Basement: Bedrooms: 3 Baths: 2 Half-baths: 1 |
|||
| 195003 |
Price Code: [D]
|
Total Finished Area: 927 sq. ft. |
 Click on thumbnail for larger image... |
|
Small & Narrow Lot Duplex This duplex plan was designed with not only a narrow lot in mind but a small lot as well, yet it still has the amenities to make for comfortable living. Two bedrooms and a bath upstairs and an open living area down with a powder room for company has what you need for a perfect starter home.Floor Areas; Main Floor: 934 sq. ft. (467 per unit) Second Floor: 920 sq.ft. (460 per unit). Click here for plans. |
|||
|
Main Floor Area: 467
Second Floor Area: 460 Third Floor Area:
Basement Area: Loft/Bonus Rm Area:
Width: 21'6" Depth: 61'0" Max. Ridge Height: 25'4" Roof Pitch - Primary: 5.00/12 Secondary: /12 Exterior Wall: 2x6 Ceiling Height - Main: 9'0" Second: 8'0" Loft/Bonus Rm: Basement: Bedrooms: 2 Baths: 1 Half-baths: 1 |
|||
| 140503 |
Price Code: [C]
|
Total Finished Area: 936 sq. ft. |
 Click on thumbnail for larger image... |
|
Entirely open activity area. Bathroom with laundry, bath and corner shower. Patio doors in the back at each extremity for more privacy. Different front elevations for both sections. Click here for plans. |
|||
|
Main Floor Area: 936
Second Floor Area: Third Floor Area:
Basement Area: 936 Loft/Bonus Rm Area:
Width: 52'0" Depth: 36'0" Max. Ridge Height: 20'6" Roof Pitch - Primary: /12 Secondary: /12 Exterior Wall: 2x6 Ceiling Height - Main: 8'0" Second: Loft/Bonus Rm: Basement: 8'0" Bedrooms: 2 Baths: 1 Half-baths: |
|||
| 200512 |
Price Code: [E]
|
Total Finished Area: 964 sq. ft. |
 Click on thumbnail for larger image... |
|
A Very Popular Plan This is a very popular plan because of its economical design and ease of construction...there is plenty of room, lots of closet space and good potential for future development in the basement. The large front deck offers privacy and is well-protected from the elements. There is the added bonus of covered parking in the drive-under carport which has access directly into the basement. Click here for plans. |
|||
|
Main Floor Area: 964
Second Floor Area: Third Floor Area:
Basement Area: 772 Loft/Bonus Rm Area:
Width: 44 (Total Depth: 50 Max. Ridge Height: Roof Pitch - Primary: 4.00/12 Secondary: /12 Exterior Wall: 2x6 Ceiling Height - Main: 8 Second: Loft/Bonus Rm: Basement: 8 Bedrooms: 3 Baths: 1 Half-baths: |
|||
| 201441 |
Price Code: [E]
|
Total Finished Area: 1044 sq. ft. |
 Click on thumbnail for larger image... |
|
Excellent Starter home This very practical three bedroom home is ideal for families looking for their first house. Open planning helps to give this design a very roomy feel, and the front covered patio extends the living space outdoors. The kitchen is handy to the utility, and with the lavatory close by this area doubles as a mudroom. Click here for plans. |
|||
|
Main Floor Area: 543
Second Floor Area: 501 Third Floor Area:
Basement Area: Loft/Bonus Rm Area:
Width: 20 Depth: 68 Max. Ridge Height: Roof Pitch - Primary: 5.00/12 Secondary: /12 Exterior Wall: 2x6 Ceiling Height - Main: 8 Second: 8 Loft/Bonus Rm: Basement: Bedrooms: 3 Baths: 1 Half-baths: 1 |
|||
| 201198 |
Price Code: [E]
|
Total Finished Area: 1063 sq. ft. |
 Click on thumbnail for larger image... |
|
Nicely Proportioned This nicely proportioned two bedroom duplex has the potential of a one bedroom suite downstairs with shared laundry facilities. This is a good open plan with a very spacious feel, large rooms and lots of closet space spell success. Many pleasant hours will be enjoyed in the combination kitchen, dining and livingroom...and the bay window adds a nice touch as does the spindled railing of the open staircase. Click here for plans. |
|||
|
Main Floor Area: 1024
Second Floor Area: Third Floor Area:
Basement Area: 996 Loft/Bonus Rm Area:
Width: 36 Depth: 56 Max. Ridge Height: Roof Pitch - Primary: 4.00/12 Secondary: /12 Exterior Wall: 2x6 Ceiling Height - Main: 8 Second: Loft/Bonus Rm: Basement: Bedrooms: 2 Baths: 1 Half-baths: |
|||
| 201406 |
Price Code: [A]
|
Total Finished Area: 1088 sq. ft. |
 Click on thumbnail for larger image... |
|
Compact And Charming With a total area of 1088 sq. ft. you will be surprised at the features we've packed into this charming design. The two-storey ceiling over the livingroom takes this plan from ordinary to extraordinary and makes it live much larger than it is. The covered patio at the front and rear extends the living space even further, and the bay-windowed nook adds an elegant touch. Click here for plans. |
|||
|
Main Floor Area: 539
Second Floor Area: 549 Third Floor Area:
Basement Area: Loft/Bonus Rm Area:
Width: 19'6 Depth: 67 Max. Ridge Height: Roof Pitch - Primary: 5.00/12 Secondary: /12 Exterior Wall: 2x6 Ceiling Height - Main: 8 Second: 8 Loft/Bonus Rm: Basement: Bedrooms: 3 Baths: 1 Half-baths: 1 |
|||
| 195025 |
Price Code: [L]
|
Total Finished Area: 1094 sq. ft. |
 Click on thumbnail for larger image... |
|
Compact Four-Plex This compact four unit townhouse will fit your needs in many small lot situations while giving all the amenities of larger units. Three bedrooms and a bathroom upstairs and all the living on the main floor with its own powder room and laundry make for a comfortable home. Floor Areas are as follows; Main Floor: 2170 sq. ft. (543 per unit) Second Floor: 2205 sq.ft. (551 per unit) Deck Area: 578 sq.ft. (144 per unit) Click here for plans. |
|||
|
Main Floor Area: 543
Second Floor Area: 551 Third Floor Area:
Basement Area: Loft/Bonus Rm Area:
Width: 41'9 Depth: 70'1 Max. Ridge Height: 33'3 Roof Pitch - Primary: 8.00/12 Secondary: /12 Exterior Wall: 2x6 Ceiling Height - Main: 8'0 Second: 8'0 Loft/Bonus Rm: Basement: Bedrooms: 3 Baths: 1 Half-baths: 1 |
|||
| 195088 |
Price Code: [D]
|
Total Finished Area: 1104 sq. ft. |
 Click on thumbnail for larger image... |
|
Very Narrow Lot Duplex This duplex will neatly fit into many narrow lots giving you a very livable and economical design. Three bedrooms upstairs, and an open living area downstairs with a powder room and laundry, all the features you need in a small space. Click here for plans. |
|||
|
Main Floor Area: 549
Second Floor Area: 555 Third Floor Area:
Basement Area: Loft/Bonus Rm Area:
Width: 21'0" Depth: 66'0" Max. Ridge Height: 23'0" Roof Pitch - Primary: 5.00/12 Secondary: /12 Exterior Wall: 2x6 Ceiling Height - Main: 8'0" Second: 8'0" Loft/Bonus Rm: Basement: Bedrooms: 3 Baths: 1 Half-baths: 1 |
|||
