Plan No.342502

Garage with Apartment

This bungalow style garage plan can house up to 5 cars. The larger two car door is 16' wide and 8' tall, while the smaller door is 9' wide and 8' tall. This garage plan also has a guest apartment on the second floor. The guest apartment features a walk-in closet with full bathroom in the bedroom. As well as a fireplace in the great room that can be enjoyed from the kitchen and nook. There is also a utility room that is accessed through the kitchen. *Materials list available. Call 1-800-361-7526 for more information.

Specifications

Total 1999 sq ft

  • Main: 1200
  • Second: 799
  • Third: 0
  • Loft/Bonus: 0
  • Basement: 0
  • Garage: 0

Rooms

  • Beds: 1
  • Baths: 2
  • 1/2 Bath: 0
  • 3/4 Bath: 0

Ceiling Height

  • Main: 9'0
  • Second:
  • Third:
  • Loft/Bonus:
  • Basement:
  • Garage:

Details

  • Exterior Walls: 2x6
  • Garage Type: fourGarage
  • Width: 40'0
  • Depth: 46'0

Roof

  • Max Ridge Height: 26'0
  • Comments: (Main Floor to Peak)
  • Primary Pitch: 6/12
  • Secondary Pitch: 0/12
Full Rendering – westhomeplanners.com
First & Second Floor – westhomeplanners.com
REAR Elevation – westhomeplanners.com
LEFT Elevation – westhomeplanners.com
RIGHT Elevation – westhomeplanners.com
